Track assets easily with a lightweight, all-touch design

In an increasingly competitive marketplace, you need to stay a step ahead with asset tracking that’s easy, intuitive and efficient. The Zebra TC22R Integrated Handheld RFID Reader provides an integrated, lightweight, all-touch design that helps your associates keep track of assets and inventory for extended periods with less fatigue. Capture data in less time and with less effort using a TC22R handheld reader that delivers industry-leading performance, such as read rates up to 1,300 tags per second, in an all-in-one form factor.

And with the latest Bluetooth® and Wi-Fi capabilities, the TC22R handheld reader offers easy deployment that gives your business a competitive edge.

Industry-Leading Performance

With a robust read rate of up to 1,300 tags per second, the TC22R handheld reader enables greater insights into asset movement and real-time data from the first mile to the last or from the front of the store to the back. In addition, because the TC22R handheld reader has an integrated NFC reader built-in that assists with mobile POS applications, you can capture data in less time and with less effort.

Easy Connectivity

With Wi-Fi 6 and Bluetooth, the TC22R handheld reader is easy to use and manage across your network. That means implementation takes less training time, allowing you to reduce deployment timelines and streamline configuration.

Get the Most Out of Your RFID Investment—From the Leader in RFID

Zebra has more fixed, handheld and portal RFID systems installed than any other RFID provider, giving you the peace of mind that comes from choosing RFID products that are well-tested in practically every industry—and in some of the world’s largest companies. And with over 300 RFID technology patents that have allowed us to deliver many industry firsts, you can count on our best-in-class advanced technologies to maximize the performance of your RFID solution.

Ergonomic Design for All-Day Comfort

The TC22R handheld reader combines real-time visibility with simplicity and ease of use. This lightweight reader enables workers to continue cycle counts with less fatigue than heavier devices. That means you get the high performance that comes with field-proven Zebra software in a compact, all-in-one device.

Simplified Deployment

The TC22R handheld reader offers a fully integrated Android-based solution that can be supported by mainstream MDMs, reducing deployment headaches and management overhead.

Dimensions
  • 5.7 in. H x 3.3 in. W x 6.96 in. L
  • 14.5 cm H x 8.4 cm W x 17.7 cm L
Weight
20.07 oz. / 569 g
Display
6.0 in. color Full High Definition+ (1080 x 2160), LED backlight, 450 nits
Touch Panel
Multi-mode capacitive touch with bare or light gloved fingertip input
Power
User-removable, quick-release, rechargeable 7,000 mAh Li-Ion battery with PowerPrecision+ for real-time battery metrics
Network Connections
WLAN, WPAN
Notifications
Audible tone, vibration
Indicators
Decode LEDs, battery status LED, beeper
Keypad
On-screen keypad
Buttons
User-programmable button for barcode scanning (default), PTT or other use, volume up/down, power
User Input
Tri-function user-programmable trigger
Interface Ports
USB 3.1 (Bottom Type C), Super Speed (host and client)
Operating Temperature
14° F to 122° F / -10° C to +50° C
Storage Temperature
-40° F to 158° F / -40° C to +70° C
IP Sealing
IP65
Humidity
5–95% non-condensing
Electrostatic Discharge
  • ±15 kV air discharge
  • ±8 kV direct discharge
Tumble Specification
500 cycles (1,000 drops, 1.6 ft./0.5 m) at room temperature
Drop Specification
Multiple 5 ft./1.5 m drops to concrete
CPU
5430 hexa-core 2.1 GHz
Memory
6 GB RAM / 64 GB Flash
Standards Supported
EPC Class 1 Gen 2; EPC Gen 2 V2
RFID Engine
Zebra Proprietary Radio Technology
Maximum RFID Read Rate
Up to 1,300 tags/sec
Nominal RFID Read Range - Integrated Antenna
40 ft. / 12.2 m
Frequency Range and RF System Output
  • US: 902–928 MHz; 0–36 dBm (EIRP)
  • EU: 865–868 MHz; 0–33 dBm (ERP) 916.3, 917.5, and 918.7 MHz; 0–36 dBm (ERP)
  • Japan: 916–921 MHz (w LBT), 0–36 dBm (EIRP)
Integrated RFID Antenna Gain
4 dBi
Scanning
SE4710 1D/2D scan engine
Camera
Forward-facing 16 MP camera, front-facing 5 MP camera
NFC
NFC ISO 14443 Type A and B; Mifare, FeliCa and ISO 15693 cards, NFC Forum tags 2,3,4,5; Host Card Emulation, Contactless Payment Support
Bluetooth
Class 2, Bluetooth v5.2
