UniTech MS838

Images may not reflect the actual product
Product Image
small product image0
small product image1
small product image2

Delivering reliable performance and affordable price, MS838 2D imager scanner offers excellent performance for increasing productivity even when the barcodes are damaged or poorly printed. This cost-effective and reliable handheld scanner provides the optimum combination of performance which makes it an ideal scanning tool for a wide range of market applications, such as point-of-sale, personal data identification and inventory control.

Features

  • Reliable performance, affordable price
  • Fast reading all 1D and 2D barcodes on paper and screen
  • Quick decoding 3mil barcode even with damaged or poorly printed
  • Supports trigger mode & presentation mode.
  • Durable design: 1.5 meters drop test and IP52-rated

Reliable Performance, Affordable Price

Delivering users an affordable price, MS838 2D imager scanner offers excellent performance for increasing productivity even when the barcodes are damaged or poorly printed. The MS838 has the capability to read up to 3 mil barcode (Code 39). This device is a brilliant choice for various industrial application requirements for retail stores, supermarket, pharmacy and hotel.

Easy to Operate

Featuring a convenient plug-and-play design, the MS838 imager scanner is easy to connect to your computer via USB/RS232 cable. There is no need to do any additional installation or training, it’s ready to work. In addition, it supports trigger mode, presentation mode(auto-sensing mode) that effectively meeting requirements for all industrial use.

Durable Design

This ergonomic design makes the MS838 fit comfortably in any hand, reducing fatigue during long-time scanning tasks. Additionally, the MS838 features an IP52 rating and can withstand multiple drops to concrete from 1.5 meters, ensuring durability and reliability.

Sensor
640 X 480 CMOS
Aiming Element
Red LED
Illumination
White LED
Ambient Light
0~100,000lux (natural light)
Scan Rate
60fps
Skew Angle
±60°
Pitch Angle Sensor
±60°
Roll Angle
0 - 360°
Optical Resolution
(1D)≥3mil
Depth of Field
60-360mm (13 mil PCS=90%)
Host Interface supported
USB / RS232
Dimension
174mm × 72mm × 96mm (L x W x H)
Weight
245g
Trigger Switch Life
1 million times
Operation Mode
Trigger Mode, Presentation Mode
1D Barcodes
Code 128, EAN-13, EAN-8, Code 39, Code 32, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, Code 93, GS1-128, GS1 Databar, GS1 Databar Limited, GS1 Databar Expanded, Matrix 2 of 5, Code 11, Industrial 2 of 5, Matrix 2 of 5,
2D Barcodes
PDF417, Micro PDF417, QR Code, Micro QR, Data Matrix, Aztec Code
Data Formatting
Prefix, Suffix, Code ID, Reformatting Date
Current Consumption
Operation mode: <142mA, Standby mode: <42mA
Indicator
Buzzer, LED
Mechanical Shock
1.5m onto concrete
Operating Temperature
-10°C to 50°C
Storage Temperature
-20°C to 60°C
Relative Humidity
5%-95% non-condensing
IP Rating
IP52
Regulatory Approvals
CE, FCC, BSMI, VCCI
The standard package contents
  • MS838 Scanner
  • Interface cable
  • Hands-Free Stand (optional)
Hardware Warranty
15 months
MS838 User Manual
Download

Shop MS838 Models

MS838-2UCB0S-SG

MS838, 2D Imager, USB Cable and Stand (Wired).

Stand Included:

Stand Included

Wired or Wireless:

Wired

$68.00

MS838-2UBB0D-SG

MS838B, 2D Imager, 3-in-1 USB &amp; BT (Wireless).

Wired or Wireless:

Wireless

$145.94

MS838-2UCB00-SG

MS838, 2D Imager, USB Cable, No Stand (Wired).

Wired or Wireless:

Wired

$62.75

Shop MS838 Accessories

1550-905928G

MS836B/MS838B USB Micro to USB 2.0 Type A cable, 80cm.

$15.50

5200-900014G

Hands Free Stand for MS838, MS838B, MS836, MS836B.

$14.25

5500-900098G

USB Dongle 2.4GHZ for MS836B/MS838B.

$16.50
